GENERAL
| Capacity | 650VA |
| Dimension ‘mm’ | 286 x 96 x 138 ‘D x W x H’ |
| Weight ‘kg’ | 4.3 |
INPUT
| Voltage Range | 162 ~ 290VAC ‘Single boost’140 ~ 300VAC ‘Double boost’ |
| Frequency | 50Hz/60Hz ‘Auto-sensing’ |
| Phase | Single + GND |
OUTPUT
| Voltage Range | 220-240VAC |
| Battery Mode | 220-240VAC |
| Frequency | 50Hz ±1% ‘Battery mode’ |
| Waveform | Simulated sine wave ‘Battery mode’Sine wave ‘AC mode’ |
| Transfer Time | 2ms typical |
BATTERY
| Type | 12V/8.2AH x 1 |
| Backup Time | 8 – 20 mins depending on the load |
| Recharge Time | 2-4 hours recover to 90% capacity |
INTERFACE & INDICATORS
| Interface | RS232, USB port, RJ45/RJ11 ‘Optional’ |
| Display | LED/LCD Optional |
| Alarm | Batt. Mode, low battery, overload, fault, etc. |
PROTECTION/MONITORING
| Short Circuit Protection | Yes ‘Line mode & battery mode’ |
| Surge Protection | Yes |
| Alarm | Audible & Visual |
| Overload Protection | Line mode: 100 – 120% 1 min change to fault mode >120% change to fault mode immediatelyBattery mode: 100 – 120% 1 min change to fault mode >120% change to fault mode immediately |
| Intelligent Battery | Prevent overcharging of battery |
| Management | Protect battery and prolong battery life |
Real Panel
| 1. AC Mode IndicatorGreen LED Lighting
2. Battery Mode Indicator Battery Normal: Yellow LED Lighting and Blinking every 30s 3. Overload and Fault Indicator Overload: Red LED Blinking every 2s 4. Power Switch 5. Power AC Input 6. Backup Outlets |
