Projection System
3LCD Technology, RGB liquid crystal shutter
LCD Panel
55 inch with C2 Fine
Color Light Output
3,300 Lumen- 2,200 Lumen ‘economy’ In accordance with IDMS15.4
White Light Output
3,300 Lumen – 2,200 Lumen ‘economy’ In accordance with ISO 21118:2012
Resolution
XGA, 1024 x 768, 4:3
Aspect Ratio
4:3
Contrast Ratio
15,000 : 1
Light source
Lamp
Lamp
UHE, 210 W, 6,000 h durability, 12,000 h durability ‘economy mode’
Keystone Correction
Manual vertical: ± 30 °, Manual horizontal ± 30 °
Colour Video Processing
10 Bits
2D Vertical Refresh Rate
100 Hz – 120 Hz
Colour Reproduction
Upto 1.07 billion colours
Throw Ratio
1.44 – 1.95:1
Zoom
Digital, Factor: 1.35
Lens
Optical
Screen Size
30 inches – 350 inches
Projection Distance Wide/Tele
1.76 m ‘ 60 inch screen’
Projection Lens F Number
1.44
Projection Lens Focal Length
16.7 mm
Projection Lens Focus
Manual
Offset
8 : 1
USB Display Function
2 in 1: Image / Mouse
Interfaces
VGA in, HDMI in, USB 2.0 Type B
Epson iProjection App
Ad-Hoc / Infrastructure
Security
Kensington lock, Security bar, Password protection
3D
No
2D Colour Modes
Dynamic, Cinema, Presentation, sRGB, Blackboard
Other features
AV Mute Slide, Auto source search, Built-in speaker, Horizontal and vertical keystone correction, Long lamp life, Quick Corner, Split-Screen-Function
Video Color Modes
Blackboard, Cinema, Dynamic, Presentation, sRGB
Power consumption
327 Watt, 225 Watt ‘economy’, 0.3 Watt ‘standby’, On mode power consumption as defined in JBMS-84 286 Watt
Supply Voltage
AC 100 V – 240 V, 50 Hz – 60 Hz
Product dimensions
302 x 237 x 82 mm ‘Width x Depth x Height’
Product weight
2.4 kg
Noise Level
Normal: 37 dB ‘A’ – Economy: 28 dB ‘A’
Supported Temperature
Operation 5° C – 25° C, Storage -10° C – 60° C
Supported Humidity
Operation 20% – 80%, Storage 10% – 90%
If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.
Options
Soft carry case
Loudspeaker
2 Watt
