Imaging
Lens Mount
Canon Mount
Camera Format
APS-C
Pixels
18MP
Aspect Ratio
3:2
Sensor Size
Approx. 22.3 mm x 14.9 mm
Exposure Control
ISO Sensitivity
AUTO(100-6400), 100-6400 in 1-stop increments ISO can be expanded to H: 12800
During Movie shooting: Auto (100-6400), 100-6400 (Whole stop increments)
Shutter Speed
30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
Exposure Modes
Evaluative via 63 zone dual-layer metering sensor (linked to all AF points)
Partial (centre, approx. 10% of viewfinder)
Centre-weighted average available
Exposure Compensation
+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).
Metering Range
Via optical viewfinder:
EV 1-20 (at room temperature, ISO 100, evaluative metering)
Via live view on LCD screen:
EV 0-20 (at room temperature, ISO 100, evaluative metering)
White Balance
Auto white balance with the imaging sensor
Continuous Shooting
Max. Approx. 3 fps in JPEG until memory card becomes full
Self-Timer
Single, Continuous, Self timer (2s, 10s, 10s + continuous shots 2-10)
Video
Recording Modes
MOV (Video: H.264 inter frame (IPB), Sound: Linear PCM, recording level can be manually adjusted by user)
External Recording Modes
Recording Limit
Max duration 29 min 59 sec, Max file size 4 GB
ISO Sensitivity
Auto (100-6400), 100-6400 (Whole stop increments)
Focus
Focus Mode
One Shot AF
AI Servo
Manual
Autofocus Points
Automatic selection from up to 9 points
Manual selection
Viewfinder and Monitor
Viewfinder Type
Pentamirror
Viewfinder Eye Point
Approx. 21mm (from eyepiece lens center)
Viewfinder Coverage
Approx. 95%
Viewfinder Magnification
Approx. 0.80x
Flash
Built-In Flash
Yes
Dedicated Flash System
HotShoe
External Flash Connection
E-TTL II with EX series Speedlite
Interface
Memory Card Slot
SD card, SDHC card or SDXC card
Connectivity
Wi-Fi
HDMI mini (Type-C) output
Wireless
Wi-Fi (IEEE802.11b/g/n), (2.4 GHz only)
Physical
Battery
1 x Rechargeable Li-ion Battery LP-E10
Environmental
Operating Humidity
0 – 40 °C, 85% or less humidity
