ASUS PRIME H610M-D D4

Rs.40,000.00

Island wide delivery within 2 days. Buy GCENTER products with confidence.

or make 3 interest free instalments of Rs..13,333.33 with Koko

Compare
Category:

PRODUCT SPECIFICATIONS
ASUS PRIME H610M-D D4

CPU :

Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors*
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
Refer to www.asus.com for CPU support list.
Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset : Intel® H610 Chipset

Memory :
2 x DIMM, Max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
Actual memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for memory support list.

Graphics :
1 x D-Sub port
1 x HDMI® port**
Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
Supports [email protected] as specified in HDMI 2.1.

Expansion Slots :

Intel® 12th Gen Processors
1 x PCIe 4.0 x16 slot
Intel® H610 Chipset
1 x PCIe 3.0 x1 slot

Storage :

Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
Intel® H610 Chipset
M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)
4 x SATA 6Gb/s ports
The M.2 slot shares bandwidth with the SATA6G_4 port. When a device in SATA mode is installed on the M.2 slot, the SATA6G_4 port cannot be used.

Ethernet :
1 x Realtek 1Gb Ethernet

USB :
Rear USB (Total 6 ports)
2 x USB 3.2 Gen 1 ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
Front USB (Total 4 ports)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports

Audio :

Realtek 7.1 Surround Sound High Definition Audio CODEC*
– Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
– Supports up to 24-Bit/192 kHz playback

Audio Features :

– Audio Shielding
– Premium audio capacitors
– Dedicated audio PCB layers
A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Back Panel I/O Ports :

2 x USB 3.2 Gen 1 ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
1 x D-Sub port
1 x HDMI® port
1 x Realtek 1Gb Ethernet port
3 x Audio jacks
1 x COM port
1 x PS/2 Keyboard/Mouse combo port

Internal I/O Connectors :

Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector

Storage related :

1 x M.2 slot (Key M)
4 x SATA 6Gb/s ports

USB :
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports

Miscellaneous :

1 x RGB header
1 x Clear CMOS header
1 x Front Panel Audio header (AAFP)
1 x LPT header
1 x S/PDIF Out header
1 x Speaker header
1 x SPI TPM header (14-1pin)
1 x 10-1 pin System Panel header

Special Features :

ASUS 5X PROTECTION III :

– DIGI+ VRM
– LANGuard
– Overvoltage Protection
– SafeSlot Core
– Stainless-Steel Back I/O

ASUS Q-Design :

– Q-DIMM
– Q-Slot

ASUS Thermal Solution :
– Aluminum heatsink design

ASUS Lighting Control
– RGB header

Software Features

ASUS Exclusive Software
Armoury Crate

AI Suite 3

– Performance And Power Saving Utility
TurboV EVO
EPU
DIGI+ VRM
Fan Xpert
ASUS CPU-Z
Norton Anti-virus software (Free Trial version)
WinRAR
UEFI BIOS
ASUS EZ DIY
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS UEFI BIOS EZ Mode

BIOS : 128 Mb Flash ROM, UEFI AMI BIOS

Manageability : WOL by PME, PXE

Accessories :

Cables :
2 x SATA 6Gb/s cables

Miscellaneous :

1 x I/O Shield
1 x M.2 ANCHOR

Installation Media :
1 x Support DVD

Documentation :
1 x User Guide

Operating System : Windows® 11 64-bit, Windows® 10 64-bit

Form Factor :
mATX Form Factor

9.2 inch x 8.0 inch ( 23.4 cm x 20.3 cm )

Brand

PRIME

Additional information

BIOS

128 Mb Flash ROM, UEFI AMI BIOS

Chipset

INTEL H610

Ethernet

1 x Realtek 1Gb Ethernet

Form Factor

Micro ATX

Manageability

WOL by PME, PXE

Socket Type

INTEL 1700 12th Gen
